Grundfos UP20-45 N 150 Stainless Steel Circulator Pump (1x230V)
Grundfos UP20-45 N 150: wet-rotor circulator with stainless steel (N) pump housing for domestic water and heating circuits.
SKU: 95906472
VAT incl.(at the CBRT effective selling rate of 20.10.2026)
Free Shipping
Specifications
Product Description
Grundfos UP20-45 N 150 is a wet-rotor circulator pump with a stainless steel pump housing (N version), suitable also for domestic hot water circuits. Technical data - Model: UP20-45 N 150 - Grundfos product no.: 95906472 - Power supply: 1x230V, single-phase - Rated flow: 2.29 m³/h - Rated head: 2.94 m - Max. head: 4.5 m - Max. power input (P1): 120 W - Enclosure class: IPX2D - Insulation class: F - Motor protection: Thermal switch - Max. operating pressure: 10 bar - Pipe connection: G 1 1/4" - Port-to-port length: 150 mm - Liquid temperature: -25 – 110 °C - Ambient temperature: 0 – 40 °C - Pump housing: Stainless steel (AISI 304) - Impeller: Composite - Net weight: 3.54 kg - Approvals: CE, EAC, WEEE, RCM
