Grundfos UP20-30 N 150 Stainless Steel Circulator Pump (1x230V)
Grundfos UP20-30 N 150: wet-rotor circulator with stainless steel (N) pump housing for domestic water and heating circuits.
SKU: 59643500
VAT incl.(at the CBRT effective selling rate of 20.10.2026)
Free Shipping
Specifications
Product Description
Grundfos UP20-30 N 150 is a wet-rotor circulator pump with a stainless steel pump housing (N version), suitable also for domestic hot water circuits. Technical data - Model: UP20-30 N 150 - Grundfos product no.: 59643500 - Power supply: 1x230V, single-phase - Rated flow: 1.53 m³/h - Rated head: 1.7 m - Max. head: 3 m - Max. power input (P1): 75 W - Enclosure class: IP44 - Insulation class: F - Motor protection: Impedance protected - Max. operating pressure: 10 bar - Pipe connection: G 1 1/4" - Port-to-port length: 150 mm - Liquid temperature: 2 – 110 °C - Ambient temperature: 0 – 40 °C - Pump housing: Stainless steel (AISI 304) - Impeller: Composite - Net weight: 2.04 kg - Approvals: CE, VDE, EAC, WEEE
